Advanced flip chip assembly and testing, located at IBM Bromont - the largest OSAT in North America
Bromont, Canada site for semiconductor assembly and testing
IBM develops chiplet and advanced packaging technology capabilities to supercharge innovations for AI and logic.
By bringing multiple technologies together at the package level to increase performance and reduce cost, our frameworks enable a new paradigm for semiconductor innovations as well as a new pathway to meet AI’s increasing performance demands.
IBM’s Bromont, Canada facility transforms the world’s most advanced semiconductors into state-of-the-art microelectronic components that are used in the entire line of IBM systems as well as in a wide range of products produced by its OEM customers.
With over 50 years of package assembly and test experience, Bromont is the largest Outsourced Semiconductor Assembly and Test (OSAT) facility in North America and one of the largest exporters in Canada, manufacturing over 100,000 advanced flip chip modules each week.
fcBGA and SiP focus
- Package size from 15mm to 93mm (proof of concept up to 105mm)
- Die size from 2 x 2mm to 27 x 32 mm
- Design packaging to support: >400A
- Thermal solutions supporting: >400W
- SiP, AoP SiP, and Hybrid SiP
- Close die and components positioning
- Higher bandwidth and lower power
- Better signal integrity
- Smaller system level footprint
- >400 components per module
- >23 different PNs per module
- Dual-sided components
- Digital, Analog, Mixed Signal, RF
- Module, Wafer, and System Level Test development & characterization
- Multi-Site programming
- Test Time reduction
- Test Program Migration
- Test Pattern Conversion ( STIL, WGL )
- Probe Card, Load Board, System Level Test (SLT) Board Design, Fab and Validation
- On Load Board Test Solutions
Design
- System level integration mentality
- Design team ITAR compliant under CGP of Canada
- Most advanced set of design tools
- Customized automation and checking
Characterization
- Industry leading analytical techniques through the entire technology stack
- Physical Failure Analysis
- Materials Composition
- Process Characterization
Modeling
- Broad experience-based package reliability insight
- Mathematically-proprietary algorithms, code, properties and models
- Predicted confidence bounds statistically linked to manufacturing data
CPO - CSPO Turnkey Solution
- EIC + PIC Assembly
- Optical Fiber Array Attach
- CSOP Test
- CPO/SiP Assembly
- CPO/SiP Test
CPO Development Highlights
- Increase of fiber density
- 125μm pitch with 80μm fiber diameter
- Assembly of ribbon with 35 fibers
- Laser attach
- On-die laser
- Integrated connectors
Semiconductor assembly and testing
1972: Bromont site inauguration
1996: Worldwide supplier for gaming console processors
2016: z13 system - 8 core chip 5,2Ghz on organic
2018: SiP, small cards – Z program – encryption hardware
2022: 50 year anniversary
ITAR
- Certified engineering and manufacturing staff
- Manufacturing floor secure access controls
- Automated system tracking, secure storage, pass and reject component traceability
- Full accountability from reception to shipment
Controlled Unclassified Information (CUI)
- All ITAR controls implemented
- Dedicated team to address special requirements for CUI
- Additional reporting and monitoring of products, etc.
SECRET
- All ITAR and CUI controls implemented
- Dedicated team to address special requirements for DoD-classified work.
Full process flow capability from materials synthesis at MRL all the way through to assembly and test, Focused on enabling 3DHI technology with hybrid bonding, HD substrate enablement and DBHi bridge technology. IBM Bromont and OEM use 50 years of manufacturing experience serving both IBM and external customers for advanced flip ship, SiP and test production.
Abundance of clean energy
- The province relies heavily on hydroelectric power, a clean and renewable energy source.
- 99 percent of all energy produced in Quebec is renewable.
- Greenhouse gas (GHG) emissions from Quebec's hydroelectric generating stations are 70 times less than coal-fired power stations.
Clean energy grid
- Quebec has one of the lowest carbon-intensive electricity grids in the world.
- Quebec's power grid, the largest in North America, is one of the most reliable systems in the world.
- Since 2013, Quebec has had a Greenhouse Gas Emission Cam-and-Trade System (SPEDE) in place to combat climate change.
Plentiful water supply
- Quebec has access to ample freshwater resources, essential for the semiconductor industry.
Government commitment to sustainability
- The government of Quebec commited to reducing greenhouse gas (GHG) emissions by 37.5 percent from 1990 levels by 2030.
- Quebec has also commited to becoming carbon neutral by 2050.
IBM's development labs located in the Northeast Corridor drive semiconductor technology innovation for the future of computing.
The largest industrial research organization in the world, home to over 1,500 scientists, engineers and designing what's next in computing.
100,000 square feet of semiconductor fab space, with many of the industry's biggest breakthroughs coming from this site.
IBM Bromont leverages its partnership with C2MI to take advantage of state of the art equipment from over 70 equipment manufacturers.
As demand for chips continues to surge from AI and cloud computing advances, the Canadian and Quebec governments are partnering with IBM to solidify the future of the chip supply chain in North America by advancing the assembly, testing and packaging capabilities at IBM's plant in Bromont, Quebec.
Among the three entities, they will invest up to CAD187 million in advancing the assembly, testing, and packaging capabilities at the plant, enabling IBM to further its research and development of methods for scalable manufacturing and other advanced assembly processes.
Bromont is embarking on a journey of digital transformation, set to launch in May 2024, to elevate their semiconductor packaging and testing processes to the forefront of smart manufacturing. This initiative will build a robust data fabric foundation, facilitating the integration of advanced AI/ML technologies. The smart factory will enable predictive and real-time monitoring for quality inspections and utilize big data analytics to proactively predict equipment failures. A control tower will also be implemented to centralize critical data and insights, enabling informed decision-making across management levels. With these enhancements in asset performance and quality management, Bromont aims to improve operational efficiency and reliability, setting a new standard in the industry.
Phase 1 aims to increase the assembly and test capacity of advanced fcBGA packaging technologies, while also adding capacity for Si Photonics technologies assembly. Phase 1.5 of the expansion plan will add wafer bumping and fan-out wafer-level packaging capabilities by 2H 2026. This addition will create a complete North American solution for both R&D and high-volume manufacturing that leverages collaboration with IBM's research centers for lab-to-fab synergies. Furthermore, IBM is working with development partner C2MI, located beside IBM Bromont, to finalize plans to add wafer finishing operations for 2.5D Si Interposer and 3D solutions. Production for this addition to the C2MI site is also scheduled for 2H 2026.
